Caméra IP anti-explosion 4 Mpx - 1/3" Progressive Scan CMOS - Objectif motorisé 4.0 mm - IR LEDs Portée 30 m - Boitier en acier inoxydable 304 résistant à la corrosion - Imperméabilité IP68
Référence :
UNV-ZAF109S-IPC3614-CNEX
- Uniview
- Caméra IP turret anti-déflagration
- Gamme Pro
- 1/3" Progressive Scan CMOS
- 4 Mégapixel (2688x1520)
- Objectif 4.0mm
- 0 Lux
- IR Portée 30 m
- Compression Ultra265/H.265/H.264
- PoE IEEE 802.3af
- IR CUT
- WDR 120dB
- Fonctions intelligentes
- Interface WEB, CMS, Smartphone et NVR
- Compatible avec ONVIF
- Boîtier IP68
- Acier inoxydable
- CNEX
| Marque | UNIVIEW |
| Résolution maximale | 4 Megapixel (2688x1520) |
| Taux Main Stream | 4MP (2688*1520)@25fps; 4MP (2560*1440)@25fps; 3MP (2304*1296)@30fps; 2MP (1920*1080)@30fps |
| Taux Extra Stream | 720P (1280*720)@25fps |
| Compression | H.265+ / H265 /H.264+ / H264 / MJPEG |
| Objectif | 4.0 mm |
| Illumination minimale | 0.005 Lux / IR 30 m |
| Améliorations d'image | WDR (120 dB), BLC, 3D-NR, AWB, Privacy Masking, ROI |
| Jour / Nuit | Filtre ICR mécanique amovible |
| Interface de communication | Ethernet 10/100M BaseT | 1 RS485 |
| Accès distant | Navigateur Web, App Smartphone et Software PC Safire Control Center |
| Interopérabilité | ONVIF (Profil S, Profil G, Profil T), API |
| Alimentation | DC 12 V / 3 W, Poe IEEE 802.3af |
| Degré de protection | IP 68 |
| Caisson | Boîtier en acier inoxydable 304 résistant à la corrosion |
| Certificat | CNEX |
| Temp. fonctionnement | -25º C ~ +60º C |
| Dimensions | Φ150*168mm |
| Poids | 4 kg |
